INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER
5
Read the message in the "Welcome"
window and then click the [Next]
button.
6
Click the [Printer Driver] button.
• To install the PC-Fax driver, click the [PC-Fax Driver]
button.
• To view information on the software, click the [Display
Readme] button.
7
Click the [Next] button.
8
Click the [Custom installation] button.
9
When you are asked how the printer is
connected, select [Connected to this
computer] and click the [Next] button.
10
When the model selection window
appears, select the model name of your
machine and click the [Next] button.
11
When the printer driver selection
window appears, remove the [PCL6]
checkmark and click the [PCL5c], [PS]
or [PPD] checkbox so that a checkmark
( ) appears, and then click the [Next]
button.
• When the PC-Fax driver is being installed, this
screen does not appear. Go to the next step.
• The PS3 expansion kit is required to use the PS
printer driver.
• The [PPD] checkbox only appears if you are using
Windows 2000/XP/Server 2003.
