Installation

INSTALLING THE TD CARTRIDGE

Remove the CAUTION tape from the front cover and remove the two protective pins

from the fusing unit by pulling the strings upward one at a time.

CAUTION tape Protective pins

Push gently on both sides of the front cover to open the cover.

Remove the TD cartridge from the bag. Remove the protective paper. Hold the cartridge

on both sides and shake it horizontally four or five times.

4 or 5 times

Hold the tab of the protective cover and pull the tab to your side to remove the cover.
