SETUP IN A WINDOWS ENVIRONMENT

INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER

To install the printer driver or the PC-Fax driver, follow the appropriate procedure in this section depending on whether

the machine is connected to a network or connected by USB cable.

☞ WHEN THE MACHINE WILL BE CONNECTED WITH A USB CABLE (page 1-89 in the Operation Guide)

WHEN THE MACHINE IS CONNECTED TO A NETWORK

This section explains how to install the printer driver and the PC-Fax driver when the machine is connected to a

Windows network (TCP/IP network).

 Standard installation

When the software selection screen appears in step 6 of "OPENING THE SOFTWARE SELECTION SCREEN (FOR

ALL SOFTWARE)" (page 30), perform the steps below.

Click the [Printer Driver] button.

To install the PC-Fax driver, click the [PC-Fax Driver]

button on the "Disc 2" CD-ROM.

*The above screen appears when using the "Disc 1" CD-ROM.

• The PS3 expansion kit is required to use the PS printer driver or the PPD driver.

• To print to the machine over the Internet using the IPP function when the machine is installed in a remote location, or to

print using the SSL (encrypted communication) function, see "Printing using the IPP function and the SSL function" (page

1-87 in the Operation Guide) and install the printer driver or the PC-Fax driver.

• If the machine is connected to an IPv6-only network

The software cannot be installed by detecting the machine's address from the installer. After installing the software as

explained in "Installation by specifying the machine's address" (page 1-84 in the Operation Guide), change the port as

explained in "Changing to a Standard TCP/IP Port" (page 1-105 in the Operation Guide).

• The installation procedure in this section is for both the printer driver and the PC-Fax driver, although the explanations are

centred on the printer driver.
