Telephone Billing
186
1
Load the document (s).
• If you are using Normal Dialing, press
or pick up an extension phone
connected to the same line.
• SEND READY will appear in the
display.
2
Enter your number to access an outside line (max. of 3 digits).
3
Flip down the Rapid Key overlay and press , enter the billing
code (max. of 9 digits), and then press again.
• Note: The code will appear as asterisks in the display and will not appear in
the Activity List or Transaction Report.
4
Press and/or to adjust the resolution and contrast if
desired.
5
Dial the other party by the desired method and transmit the document.
SPEAKER
Space
Space
RESOLUTION
CONTRAST
