Preparation before Use
2-5
Connecting Cables
Follow the steps below to connect cables to the machine.
1 Connect the machine to the PC or your network device.
When using the network interface, remove the cap.
When connecting the network cable, configure the
network. For details, refer to Network Setup (LAN Cable
Connection) on page 2-13.
2 Connect one end of the supplied power cable to the
machine and the other end to a power outlet.
IMPORTANT: Only use the power cable that comes with the machine.
