LPKF ProtoMat 95s/II commands

82 ProtoMat 95s/II

10.1.3 Special command for the high-speedcycle spindle

Before communicating with the high-speedcycle spindle, send the

command for opening the SERIAL2 (!OC;), then the serial interface

SERIAL2" must be closed again (!CC;)

!RM (r){;}

Revolutions Motor, r=0...60.

Sets the speed (r)*1000 of the high-speedcycle spindle.

10.1.4 Direct commands

Direct commands are special commands which, once they have been

interpreted, are carried out via the command buffer.

!CB{;}

Clear buffer

Deletes all commands from the command buffer.

!GO{;}

Go on

Removes the stop command and continues the command

implementation.

!RC{;}

Repeat command

Repeats the last command carried out.

!ST{;}

Stop

Interrupts command processing when the current command is

completed.

The command set implemented is a subset of the HP-GL. If the

equipment is to be driven by any CAD system, with HP-GL commands, it

must be ensured that the step size is substantially lower than with

normal pen plotters.

The step size is 6,25 µm/step (5 mm/800 steps).
