Sharp LC-22DV200E Datasheet download pdf

LC-22DV200E

• Screen Size 56 cm (22")

• HD ready panel (1366 x 768)

• Freeview

• LCD TV

• Build in DVD drive including media player

• Additional HDMI port for external sources

The functional and room saving multi talent combines an LCD TV and a slot-in DVD drive delivering all the

entertainment devices needed at the convenient reach of a finger tip on one remote control. All this without losing

expandability through several connection possibilities.

Display

• Visible diagonal screen size cm / inch: 56 / 22

• Panel resolution: 1366 x 768

• Panel technology RGBY / RGB: no/yes

• Panel sub pixels 8 Mega / 6 Mega: no/no

• Panel technology 3D / UV²A: no/no

• Panel colour processing

• HD ready 1080p / HD TV 1080p: no/no

• HD ready / HD TV: no/yes

• Backlight system LED / CCFL: no/yes

• Backlight type full / edge: yes/no

• E-motion 200 / 100Hz E-motion: no/no

• Scanning backlight / local dimming / film dejudder:

no/no/no

• Smart AV Mode II / Mode I: no/no

• Brightness (cd/m²) / contrast ratio: 300 / -

• Life time (h) / Reaction time (ms): 50000 / 5

• Viewing angle horizontal / vertical: 170 / 160

Reception system

• SDTV / HDTV (MPEG4, H.264): yes/yes

• DVB-S / DVB-S2: no/no

• DVB-C / DVB-C2: no/no

• DVB-T / DVB-T2: yes/no

• Analog: yes

• Internet TV / Internet Radio: no/no

• Colour system NTSC (AV In) / PAL / SECAM: yes/yes/yes

Audio system

• Amplifier digital / 1 bit: no/no

• Automatic Volume Control AVC: yes

• Virtual / Dolby Surround: yes/yes

• Dolby Digital Plus / TrueHD (optical drive): no/no

• DTS HD / High Resolution Audio (optical drive): no/no

• Number of Speakers (without Subwoofer): 2

• Speakers: output power (W): 1.5 + 1.5

• Number of Subwoofers

• Subwoofers: output power (W)

• Soundsystem B/G, D/K, I, L/L', M: no

• Soundsystem B/G, D/K, I, L/L': yes

• HD Soundsystem MPEG4 AVC / MPEG4 AAC: yes/yes

Multimedia

• Teletext (pages): 1000

• Electronic program guide (EPG): 7 days

• Capacity of internal HD drive / internal memory (GB)

• Timeshift on internal memory / USB connected device:

no/no

• Timeshift internal approx. duration (h) HD / SD

• DLNA media player for Video / Photo / Music: no/no/no

• USB media player for Video / Photo / Music:: no/no/no

• Player for Divx HD / DivX: no/yes

Integrated optical drive

• BD drive / DVD drive: no/yes

• Region code BD / DVD: - / 2

• Profile BD-ROM R2.1 / R1.1: no/no

• BD-MV / BD-AV / DVD Video: no/no/yes

• + DVD R RW DL / - DVD R RW DL: no/yes

• Audio-CD / CD-MP3 / CD-WMA: yes/yes/yes

• 1080p24 / Upscaling / x.v.Colour: no/no/no

• BD Live: no

Connectors

• HDMI V1.4 / HDMI V1.3: - / 1

• HDMI Features : Ethernet Channel / Audio Return Channel:

no/no

• HDMI Features : 3D / 4K: no/no

• HDMI Features : Deep Color / x.v.Color: no/no

• HDMI Audio Formats : SA-CD / DVD-Audio: no/no

• HDMI Audio Formats : DTS-HD Master Audio™ / Dolby

TrueHD: no/no

• AQUOS Link / standard CEC: no/no

• SCART: 1

• AV in / S-Video in / Component in: yes/yes/yes

• Headphone / analogue audio: yes/no

• Digital audio electrical (coax) / optical: yes/no

• Common interface CI+ / CI: no/yes

• VGA / DVI / RS-232C: yes/no/no

• WLAN / LAN / USB: no/no/yes

• Dock made for ipod / works with iphone: no/no

Sharp Electronics (UK) Limited, 4 Furzeground Way, Stockley Park, Uxbridge, Middlesex UB11 1EZ. Tel. 0208 734 2000

1 2

LC-22DV200E 1

Summary of Contents

Page 1 - LC-22DV200E

LC-22DV200E• Screen Size 56 cm (22")• HD ready panel (1366 x 768)• Freeview• LCD TV• Build in DVD drive including media player• Additional HDMI p

Page 2

ECO• Energy Label Classification• AQUOS Link 2: no• No signal off, no operation off: yes• Main power switch: no• Optical picture control (OPC): no
