Sharp MX-4101N Specifications

DIGITAL FULL COLOUR MULTIFUNCTIONAL SYSTEMSafety GuideSafety GuideSafety GuideBefore installing this product, be sure to read the "CAUTIONS"

8SPECIFICATIONSMachine specifications / copier specifications (Continued)*1 Output tray (Center tray) cannot be used when the finisher or saddle stitc

9SPECIFICATIONSContinuous copying speeds** Copy speed during output of the second copy and following copies when performing continuous one-sided copyi

10SPECIFICATIONSAcoustic noise emission (measurement according to ISO7779)Automatic document feeder specifications*1 Scanning in mono 2 mode of one si

11SPECIFICATIONSExit tray unit (right tray) specifications* The maximum number of sheets that can be held varies depending on ambient conditions in th

12SPECIFICATIONSStand/2x500 sheet paper drawer specificationsLarge capacity tray specifications** A stand/1x500 sheet paper drawer or stand/2x500 shee

13SPECIFICATIONSFinisher specifications*1 The maximum number of sheets that can be held varies depending on ambient conditions in the installation loc

14SPECIFICATIONSFinisher (large stacker) specifications*1*1 Paper pass unit and stand/1x500 sheet paper drawer or stand/2x500 sheet paper drawer are r

15SPECIFICATIONSSaddle stitch finisher specifications*1*1 Paper pass unit and stand/1x500 sheet paper drawer or stand/2x500 sheet paper drawer are req

16SPECIFICATIONSPunch module specifications (for finisher)Punch module specifications (for finisher (large stacker))ModelMX-PNX1A MX-PNX1B MX-PNX1C MX

17SPECIFICATIONSPunch module specifications (for saddle stitch finisher)Keyboard specificationsPrinter specifications*1 When the PS3 expansion kit is

EMC (this machine and peripheral devices)Caution!For complete electrical disconnection, pull out the main plug.The socket-outlet shall be installed ne

18SPECIFICATIONSNetwork scanner / Internet Fax*1 specifications*1 Internet fax expansion kit is required.*2 Enhanced compression kit is required.*3 To

19Facsimile specifications*1 Transmission speed is for an A4 or 8-1/2" x 11" document with approximately 700 characters at standard resoluti

INFORMATION ON DISPOSALA. Information on Disposal for Users (private households)1. In the European UnionAttention: If you want to dispose of this equi

21Information that the administrator of the machine requires is printed on the back of this page.(Separate this page from the manual and keep it in a

22TO THE ADMINISTRATOR OF THE MACHINE(Separate this page from the manual and keep it in a safe place.)Factory default passwordsWhen accessing the syst

23TO THE ADMINISTRATOR OF THE MACHINETrademark acknowledgmentsThe following trademarks and registered trademarks are used in conjunction with the mach

Sharpdesk CD-ROM (for Windows)47Installing SHARP TWAIN AR/DMSHARP TWAIN AR/DM cannot be used in Windows Vista.1Quit any software applications and/or r

46Sharpdesk CD-ROM (for Windows)6When the "Customer Information" window appears, enter the serial number thatappears on the cover of the thi

1For the users of the fax functionFAX interface cable and Line cable:These special accessories must be used with the device.The Declaration of Conform

Sharpdesk CD-ROM (for Windows)45Installing the Software ProgramNote the following when installing the software program from the CD-ROM:●Be sure to che

44Sharpdesk CD-ROM (for Windows)User's Guides for Software ProgramsThe Manual folder in the CD-ROM contains user's guides (in PDF format) fo

43Sharpdesk CD-ROM (for Windows)The CD-ROM contains the following software programs:●Sharpdesk* (Desktop Document Management Software)●Network Scanner

42Sharpdesk Installation GuidePlease read●The explanations in this manual assume that the person who will install the product and the users of the pro

41REMOVING THE SOFTWARETo remove the printer driver or software installed using the installer, follow the steps below.Windows1Click the [start] button

40WHEN INSTALLATION WAS NOT SUCCESSFULX The printer driver cannot be installed (Windows 2000/XP/Server 2003)If the printer driver cannot be installed

39WHEN INSTALLATION WAS NOT SUCCESSFULThe machine is not detected (when connected to a network).Is the machine power on? If the machine is powered off

38WHEN INSTALLATION WAS NOT SUCCESSFULThis section provides solutions to possible installation problems. See the following table of contents to locate

37MAC OS 9.0 - 9.2.210Select the PPD file.(1) Click the PPD file for your model.(2) Click the [Select] button.11Make sure that the machine is selected

36MAC OS 9.0 - 9.2.21Insert the "Software CD-ROM" into your computer's CD-ROM drive.Insert the "Software CD-ROM" that shows &

2ContentsThe products that meet the ENERGY STAR® guidelines carry the logo shown above.The products without the logo may not meet the ENERGY STAR® g

35MAC OS XX Printing using the IPP functionThe machine can print using the IPP function. When the machine is in a remote location, this function can b

34MAC OS X15Display printer information.(1) Click the machine's name.If you are using Mac OS X v10.5 to 10.5.1, click the [Options & Supplies

33MAC OS X+14Configure the printer driver.• The procedure for configuring the printer driver varies depending on the operating system version. The pro

32MAC OS X7The License Agreement window will appear. Make sure that you understand the contents of the license agreement and then click the [Continue]

31This chapter explains how to install the PPD file to enable printing from a Macintosh and how to configure the printer driver settings.☞ MAC OS X: t

304Select [SC2 TCP/IP Port] and then click the [New Port] button.In Windows 98/Me, select [Other], [SC2 TCP/IP Port], and then click the [OK] button.5

29CHANGING THE PORTWhen using the machine in a Windows environment, follow the steps below to change the port when you have changed the IP address of

28INSTALLING THE PS DISPLAY FONTSFonts that can be used by the PS printer driver are contained on the "PRINTER UTILITIES" CD-ROM that accomp

27INSTALLING THE SCANNER DRIVER7Select the IP address of the machine from the "Address" menu and click the [OK] button.• Be sure to ask your

26INSTALLING THE SCANNER DRIVERThe scanner driver (TWAIN driver) can only be used when the machine is connected to a network. When the scanner driver

3CAUTIONS1. Do not touch the transfer belt. Scratches or smudges on the transfer belt will cause dirty prints.2. The fusing unit is extremely hot. Ex

25INSTALLING THE PRINTER STATUS MONITORPrinter Status Monitor is a printer utility that allows general users to check the current status of the machin

24INSTALLING THE PRINTER DRIVER / PC-FAX DRIVERX When the PPD driver is installed1Click the [Start] button ( ), click [Control Panel], and then click

23INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER5Configure the image of the machine.An image of the machine is formed in the printer driver configurati

22INSTALLING THE PRINTER DRIVER / PC-FAX DRIVERCONFIGURING THE PRINTER DRIVER FOR THE OPTIONS INSTALLED ON THE MACHINEAfter installing the printer dri

21INSTALLING THE PRINTER DRIVER / PC-FAX DRIVERUSING THE STANDARD WINDOWS PS PRINTER DRIVER (Windows 98/Me/NT 4.0)If the PS3 expansion kit is installe

20INSTALLING THE PRINTER DRIVER / PC-FAX DRIVERUSING THE MACHINE AS A SHARED PRINTERIf you are going to use the machine as a shared printer on a Windo

19INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER6Select whether or not you wish the printer to be your default printer and click the [Next] button.If y

18INSTALLING THE PRINTER DRIVER / PC-FAX DRIVERWhen installing the PCL5c printer driver, PS printer driver, PPD driver, or PC-Fax driverInstallation i

17INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER6Click the [Close] button in the window of step 1.When a message appears prompting you to connect the m

16INSTALLING THE PRINTER DRIVER / PC-FAX DRIVERWHEN THE MACHINE WILL BE CONNECTED WITH A USB CABLESupported operating systems: Windows 98/Me/2000*/XP*

4CAUTIONSLaser informationWave length 790 nm ±10 nmPulse times(North America and Europe)MX-4100N/MX-4101N:3.5 µs ±3.5 ns /7 mm Heavy Paper 3.2 µs ±3.2

15INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER5Enter the machine's URL and click the [Next] button.Enter the URL in the following format:Normal

14INSTALLING THE PRINTER DRIVER / PC-FAX DRIVERX Printing using the IPP function and the SSL functionThe IPP function can be used to print to the mach

13INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER5When the model selection window appears, select the model name of your machine and click the [Next] bu

12INSTALLING THE PRINTER DRIVER / PC-FAX DRIVERX Installation by specifying the machine's addressWhen the machine cannot be found because it is n

11INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER6When you are asked whether or not you want the printer to be your default printer, make a selection an

10INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER2Click the [Standard installation] button.3Printers connected to the network are detected. Select the m

9INSTALLING THE PRINTER DRIVER / PC-FAX DRIVERTo install the printer driver or the PC-Fax driver, follow the appropriate procedure in this section dep

8This section explains how to install the software and configure settings so that the printer and scanner function of the machine can be used with a W

7CONNECTING THE MACHINECONNECTING TO A NETWORKTo connect the machine to a network, connect the LAN cable to the machine's network connector. Use

6VERIFYING SYSTEM REQUIREMENTSSOFTWARE REQUIREMENTSThe following requirements must be met to use the software described in this manual.*1 For the type

5INSTALLATION REQUIREMENTSImproper installation may damage this product. Please note the following during initial installation and whenever the machin

5VERIFYING SYSTEM REQUIREMENTSSYSTEM REQUIREMENTSBefore installing the software described in this manual, make sure that your computer satisfies the f

4CD-ROMS AND SOFTWAREOTHER CD-ROMSX "PRINTER UTILITIES" CD-ROM that accompanies the PS3 expansion kit (for Windows/Macintosh)This contains t

3CD-ROMS AND SOFTWAREDisc 2Software for Windows• PC-Fax driverThis enables you to send a file from your computer as a fax using the same procedure as

2This chapter describes the software programs that allow you to use the printer and scanner functions of the machine, the CD-ROMs that contain the sof

1TABLE OF CONTENTS1BEFORE INSTALLING THE SOFTWARECD-ROMS AND SOFTWARE. . . . . . . . . . . . . . . . . . . . 2• SOFTWARE CD-ROM . . . . . . . . . . .

Thank you for purchasing this product. This manual explains how to install and configure the software that allows the machine to be used as a printer

DIGITAL FULL COLOUR MULTIFUNCTIONAL SYSTEMSoftware Setup GuideSoftware Setup GuideSoftware Setup GuideKeep this manual close at hand for reference whe

6SUPPLIESStandard supplies for this product that can replaced by the user include paper, toner cartridges, and staple cartridges for the finisher.Be s

7SPECIFICATIONSMachine specifications / copier specifications* First copy out time is measured with original on the document glass in full ready condi
