Sharp AR-C265P User’s Guide
95
Replace the Belt Unit _______________
REPLACE BELT
355: BELT LIFE
The belt unit is located under the four image drums.
1. Press the cover release and open the top cover fully.
2. Note the positions of the four image drums: Cyan (1),
Magenta (2), Yellow (3), Black (4). It is essential that
they go back in the correct order!
WARNING!
If the printer has been powered on, the fuser is
HOT. This area is clearly labelled. Do not touch it.
