Sharp PC-A500 Specifications download pdf (Page 60)

6-5

Push the memory module into the slot firmly at an angle of about 20 degrees.

Gently push the memory module down until you hear a clicking sound

Projected Part

Notched part

Replace the RAM board slot cover. Make sure two

▼

marks face each other;

then, slide the cover to the left.

1 2 ... 55 56 57 58 59 60 61 62 63 64 65 ... 88 89
