4.23 Fluorescent Lamp 4 Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-73
2. Remove the two screws.
Figure 4-54 Replacing 15.0 Inch Samsung fluorescent lamp (XGA) (2)
3. Remove the four screws from the top chassis.
Figure 4-55 Replacing 15.0 Inch Samsung fluorescent lamp (XGA) (3)
Screw
Screw
Screw
S
crew
Screw
Screw
