Maintenance
127
10. Maintenance
6
Place the imaging film cartridge back
in the print compartment.
7
Close the print compartment cover
(press down on both sides to make
sure it clicks into place), and then
close the operation panel.
8
Reinsert the paper in the paper tray
and push the paper release plate back
down.
all-ux340L.book Page 127 Thursday, December 23, 1999 5:37 PM
