PG-C20X
The Power of Mobility and Performance
Making Great Business Impressions
The Power of Mobility and Performance
Making Great Business Impressions
TRUE XGA MICRO PORTABLE LCD PROJECTOR
Specifications
SHARP CORPORATION OSAKA, JAPAN
URL: http://www.sharp-world.com/
1N0033N © SHARP CORP. (MAR. 2001 PRINT) I 5 E Printed in Japan
Model
LCD panels
Number of pixels
Resolution
Computer RGB input signals
Video colour systems
Lens
Projection size
Projection distance
Luminance
Contrast ratio
Audio amplifier
Speakers
Input terminals
Output terminals
Power source
Power consumption
Projection lamp
Dimensions (W x H x D)
Weight
Supplied accessories
Design and specifications are current as of March 2001, but are subject to change without notice.
Optional Accessories
AN-C10BM
RGB cable
IBM VGA series (10 m)
Cables
AN-C10MC
RGB cable
Macintosh II series (10 m)
AN-C3CP
3-RCA to 15-pin
D-sub cable (3 m)
AN-C3BN
5-BNC to 15-pin
D-sub cable (3 m)
AN-C10RS
RS-232C serial
control cable (10 m)
AN-TK201
For high ceiling
installation
Ceiling Mounts
AN-TK201
For standard
ceiling installation
AN-Z7T
Installation Adaptors
PG-C20X
(Dimensional Drawings)
(unit: mm)
FrontSide Top
PG-C20X
Poly Silicon 0.9" (2.3 cm) active matrix TFT LCD x 3
2,359,296 pixels (786,432 dots x 3, in stripe pixel arrangement)
580 TV lines (video input)
SXGA/Mac 21" (in intelligent compression), XGA/SVGA/VGA/VESA, Mac 19"/16"/13"
15-80 kHz (horizontal), 43-85 Hz (vertical), 12-108 MHz (pixel clock) (plug & play VESA; DDC 1/2B)
NTSC/NTSC 4.43/PAL/PAL (60Hz)/PAL-M/PAL-N/SECAM
1:1.2 manual zoom and focus
40" (102 cm) to 250" (635 cm) diagonal
40" (102 cm) : 1.6 m-1.9 m, 100" (254 cm): 3.9 m-4.8 m, 250"(635 cm): 9.9 m -10.0 m
1000 ANSI Lumen (800 ANSI Lumen with Power Save Mode ON)
500:1
1W
2.8 cm (round) x 1 (mono)
Video x 1 (RCA), S-video x 1, audio L/R mono mixing x 1 (RCA), computer RGB/component x 1 (15-pin mini D-sub),
audio L/R x 1 (3.5mm stereo mini jack x 1), RS-232C serial port x 1 (9-pin D-sub)
Computer RGB x 1 (15-pin mini D-sub), audio L/R x 1 (3.5 mm stereo mini jack)
100-240V AC, 50/60Hz (Multi-Voltage)
230W (standby 5W)
150W NSH (1000 hour lamp life)
260 x 74 x 207 mm (main body only)
260 x 82 x 207 mm (including adjuster legs)
2.6 kg
Remote control, two AAA size batteries, power cord (1.8/3.6 m), computer cable (3 m),
computer audio cable (3 m), remote mouse receiver and cable for IBM/Mac USB (1 m),
IBM PS./2 (1 m), DIN to D-sub RS-232C cable (15 cm), extra air filter,
lens cap (attached), lens cap strap, CD-ROM, operation manuals
ON/OFF
POWER
LAMP
TEMP.
KEYSTONE
INPUT
BACK ENTER MENU
AUTO SYNC
FOCUS
ZOOM
82
207
42 32
260
8
260
