Sharp XV-Z200E Specifications download pdf (Page 8)

-7

Introduction

Ensure that you read the following safeguards when

setting up your projector.

Caution concerning the lamp unit

■ Potential hazard of glass

particles if lamp ruptures.

In case of lamp rupture,

contact your nearest Au-

thorized SharpVision

Service Center or Dealer

for a replacement.

See “Replacing the Lamp” on page 56.

Caution concerning the setup of the pro-

jector

■ For minimal servicing and to maintain high

image quality, SHARP recommends that this

projector be installed in an area free from hu-

midity, dust and cigarette smoke. When the

projector is subjected to these environments,

the vents and lens must be cleaned more of-

ten. As long as the projector is regularly

cleaned, use in these environments will not

reduce the overall operation life of the unit.

Internal cleaning should only be performed

by an Authorized SharpVision Service Cen-

ter or Dealer.

Do not set up the projector in places ex-

posed to direct sunlight or bright light.

■ Position the screen so that it is not in direct

sunlight or room light. Light falling directly on

the screen washes out the colors, making

viewing difficult. Close the curtains and dim

the lights when setting up the screen in a

sunny or bright room.

The projector may be safely tilted to a

maximum angle of 12 degrees.

■ Placement should be within ±12 degrees of

horizontal.

Warning about placing the projector in

a high position

■ When placing the projector in a high posi-

tion, ensure to secure it carefully to avoid

personal injury caused by the projector fall-

ing down.

Do not subject the projector to hard im-

pact and/or vibration.

■ Take care with the lens so as not to hit or

damage the surface of the lens.

Rest your eyes occasionally.

■ Continuously watching the screen for long

hours will cause eye strain. Ensure to occa-

sionally rest your eyes.

Avoid locations with extremes of tem-

perature.

■ The operating temperature of the projector

is from 41°F to 95°F (+5°C to +35°C).

■ The storage temperature of the projector is

from –4°F to 140°F (–20°C to +60°C).

Do not block the exhaust and intake

vents.

■ Allow at least 7

inches (20 cm) of space

between the exhaust vent and the nearest

wall or obstruction.

■ Ensure that the intake vent and the exhaust

vent are not obstructed.

■ If the cooling fan becomes obstructed, a pro-

tection circuit will automatically put the pro-

jector into standby mode to prevent overheat

damage. This does not indicate a malfunc-

tion (See pages 54 and 55.). Remove the pro-

jector power cord from the wall outlet and wait

at least 10 minutes. Place the projector where

the intake and exhaust vents are not blocked,

plug the power cord back in and turn on the

projector. This will return the projector to the

normal operating condition.

XV-Z2000U_E_P06_15.p65 04.10.13, 0:13 PM7

Downloaded From projector-manual.com Sharp Manuals
