Speciﬁ cations

MX-2610N/MX-3110N

Digital Full Colour Multifunctional System

Design and speciﬁ cations are subject to change without prior notice. All information was correct at time of print.

The ENERGY STAR logo is a certiﬁ cation mark and may only be used to certify speciﬁ c products that have been

determined to meet the ENERGY STAR programme requirements. ENERGY STAR is a US registered mark. The

ENERGY STAR guidelines apply to products only in the US, Europe, Australia, New Zealand and Japan. Windows,

Windows XP and Windows Vista are registered trade marks of Microsoft Corporation. All other company names,

product names and logotypes are trademarks or registered trademarks of their respective owners.

©Sharp Corporation January 2011 Ref: MX-2610N/MX-3110N. All trademarks acknowledged. E&OE.

834 mm

658 mm

583 mm

General

Engine speed ppm/cpm Colour B/W

MX-2610N 26 26

MX-3110N 31 31

Paper size Max. A3 wide*

, min. A5R

Paper weight Drawer: 60g/m

- 209g/m

Bypass: 55g/m

- 256g/m

Paper capacity Standard: 600 sheets (500-sheet tray and 100-sheet multi-bypass tray),

Maximum: 5,600 sheets (4 x 500-sheet trays, 100-sheet multi-bypass tray

and 3,500-sheet large capacity tray)

Warm-up time*

20 sec.

Memory Standard: Copier/Printer (shared): 3 GB

Option: Printer: 1 GB

HDD 160 GB*

Power requirements Rated local AC voltage ±10%, 50/60 Hz

Power consumption (Max.) 1.84 kW (200 to 240V)

Dimensions (W x D x H) 583 x 658 x 834 mm

Weight 74 kg

Copier

Original paper size Max. A3

First copy time*

Full colour B/W

MX-2610N 8.1 sec 5.9 sec

MX-3110N 7.9 sec 5.8 sec

Continuous copy Max. 999 copies

Resolution (Max.) Scan (colour): 600 x 600 dpi

Scan (b/w): 600 x 600 dpi, 600 x 400 dpi, 600 x 300 dpi

Print: 600 x 600 dpi, 9600*

equivalent x 600 dpi

Gradation Equivalent to 256 levels

Zoom range 25 to 400% (25 to 200% using RSPF) in 1% increments

Preset copy ratios 10 ratios (5R/5E)

Colour Network Scanner

Scan method Push scan (via operation panel), Pull scan (with TWAIN-supporting

application)

Resolution Push scan: 100, 150, 200, 300, 400, 600 dpi

Pull scan: 75, 100, 150, 200, 300, 400, 600 dpi, 50 to 9600*

dpi custom

File formats XPS*

, PDF, Encrypted PDF, JPEG, TIFF, Compact PDF*

, PDF/A

Scanner utilities Network Scanner Tool, Sharpdesk™

Scan destinations Scan to e-mail, desktop, FTP server, network folder (SMB), USB memory,

i-Fax Twain/WIA compliant application

Document Filing

Document ﬁ ling capacity Main and custom folders: 71 GB, 20,000 pages*

or 3,000 ﬁ les

Quick ﬁ le folder: 10 GB, 10,000 pages*

or 1,000 ﬁ les

Stored jobs Copy, print, direct print, scan, fax transmission*

Storage folders Quick folder, main folder, custom folder (max. 1000 folders)

Conﬁ dential storage Password protection

Network Printer

Resolution 1200 x 1200 dpi , 600 x 600 dpi, 9,600 (equivalent) *

x 600 dpi

Interface USB 2.0

10Base-T/100Base-TX/1000Base-T

Supported OS*

Standard: Windows

2000/XP, Windows

Server 2003/2008/2008R2,

Windows

Vista, Windows

Optional: Mac OS 9.0 - 9.2.2, Mac OS X 10.2.8, 10.3.9, 10.4.11,

10.5 - 10.5.8, 10.6 - 10.6.5

Network protocols*

TCP/IP (IPv4 & IPv6), IPX/SPX (Netware), NetBEUI, EtherTalk (AppleTalk)

Printing protocols LPR, Raw TCP (port 9100), POP3 (e-mail printing), HTTP,

Novell Printserver application with NDS and Bindery,

FTP for downloading print ﬁ les, EtherTalk printing, IPP

PDL emulation Standard: PCL 6

Option*

: PS3 emulation, XPS

Available fonts 80 fonts for PCL, 136 fonts for PS3 emulation*

B/W Facsimile (optional MX-FX11 required)

Compression method MH/MR/MMR/JBIG

Communication protocol Super G3/G3

Transmission time Less than 2 seconds*

Modem speed 33,600 bps to 2,400 bps with automatic fallback

Transmission resolution Standard: 203.2 x 97.8 dpi, Ultra Fine: 406.4 x 391 dpi

Recording width A3 to A5

Memory 1GB

Grey scale levels Equivalent to 256 levels

*1: An option is required for outputting A3W size paper: MX-TR12 or MX-FN17 or MX-FN10.

*2: At rated voltage. May vary depending on machine conditions and operating environment.

*3: 1GB = One billion bytes when referring to hard drive capacity. Actual formatted capacity is less.

*4: Best achieved time based on A4 copy, long-edge feeding from 1st paper drawer, using document glass,

when machine is ready, without Auto Colour Mode and Auto Colour Selection. May vary depending on

machine conditions and operating environment.

*5: Resolutions higher than 600 dpi are interpolated.

*6: To view XPS ﬁ les on PCs not running Windows Vista, you must have the XPS View application installed.

*7 Requires optional MX-EB11

*8 Measured using Sharp’s standard chart (A4 with 6% coverage B/W)

The Quick File Folder shares memory with the Job Build function; up to 10 GB of data storage is available

when using both functions. The storage capacity will be less for colour pages.

*9: Optional MX-FX11 required.

*10: Optional MX-PK11 required for Mac OS, EtherTalk and PS3.

*11: PS3 requires optional MX-PK11. XPS requires optional MX-PUX1 and MX-SM10.

*12: Based on Sharp’s standard chart with approx. 700 characters (A4 portrait ) at standard resolution in Super

G3 mode, 33,600 bps, JBIG compression.
