LOADING PAPER

Loading paper in the bypass tray

Open the bypass tray and extend the tray.

Set the bypass tray paper guides to the paper width. Insert the

paper (print face down) all the way into the bypass tray.

Press the [TRAY SELECT] key ( ) to select the bypass tray.

• Paper must be fed narrow side first into the feed slot.

• Special papers such as transparency film, labels, and envelopes

must be fed one sheet at a time through the bypass tray.

• When copying onto transparency film, remove each copy promptly.

Do not let copies stack up.

To close the bypass

tray, perform step 1

and then step 2 in

the illustration and

push the round

projections at the

right of the tray until

they click.

Note

Print face
