SF-3441 BASE

SF-8541

SF-

8541R

SF-3410 BASE

SF-3110

SF-7400

SF-3140

SF-

8500

Machine/robot-

mounted-type

transducer

Machine/robot-

mounted-type

transducer

SF-3400BASE

Manual-type

hand piecelarge

SF-9400

SF-60 BASE

Manual-type

hand piece

SF-6100

Machine/robot-

mounted-type

transduce

SF-6000

Plotting cutter-

mounted-type

transducer

HP-650

SF-650 BASE

Manual-type

hand piece

HP-650

SF-651 BASE

Machine/robot-

mounted-type

transducer

Manual-type

hand piecellarge

amplitude type

SF-

8500R

Plotting cutter-

mounted-type

large amplitude

transducer

The basic configuration is a set of an oscillator and a hand piece (transducer).

Before use, install a tool (blade) with a screw, which is necessary for the operation.

Machine/robot-mounted type

compatible with transducer

Compatible with manual-type

hand piece

Blade-holding method is patented

(Patent No.: 3462118)

SF-3441(Oscillator)

Ultrasonic cutter

Machine/robot-

mounted-type

large amplitude

transducer

Plotting cutter-

mounted-type

large amplitude

transducer

Easy to mount on automated machinery/industrial robots. Sharp cut and high-power

ultrasonic cutter with high frequency of 40,000 waves per second. Highly-versatile new

product with choice and change of blade thickness.

P5-P6

SF-3410(Oscillator)

Ultrasonic cutter

Mountable on automated machine/robot. High-power ultrasonic cutter that can be combined

with various types of transducers.

P7-P8

Increased amplitude of the blade by approximately 50% compared to the

conventional model! Ideal for cutting and cutout of three-dimensional

part by mounting in industrial robots, not to mention sheeting material

cutout.

Compact and yet powerful. Designed to fully utilize the robot's operation

area. Equipped with air inlet.

Equipped with a rotary head. The rotary connector for electric signal as

well as the air inlet rotates simultaneously.

Possible to select a horn suitable for your application and custom-make a

blade that best suits your work requirements. Ideal for up-and-down push

cut and punching.

Compatible with large tools such as chisel shape and knife shape to assist

power-requiring manual operations, including cutting of timber or cured

resin, stripping exterior walls of buildings, and rust removal.

SF-3400(Oscillator)

Ultrasonic cutter

Mountable on automated machine/robot. High-power ultrasonic cutter that can be combined

with various types of transducers.

P9-P10

Compact hand piece suitable for light labor.

Machine/robot-mounted type

Rotary connector type, plotter-mountable.

SF-60 (Oscillator)

Ultrasonic cutter

Highly-workable desktop ultrasonic cutter with stable vibrations output and an easy-to-hold

hand piece. Automated machinery/plotting cutter-mounted types also available.

P13-P14

Remarkable cut! Lightweight, easy-to-hold, and simplified tool installa-

tion with newly-developed installation system.

SF-650 (Oscillator)

Ultrasonic cutter

High-speed and high-performance ultrasonic cutter realizing a sharp cut, with user-friendly

hand piece and desktop controller.

P11

Extended and continuous use possible with our controlling circuit and

the air inlet for forced cooling.

SF-651 (Oscillator)

Ultrasonic cutter

High-speed and high-performance with remarkably sharp cut! Easy to mount on automated

machinery and industrial robots.

P12

Highly versatile hand-tool compatible with small and large blades

compatible with your application, with the provision to exchange horns

for enlarging amplitude.

SF-8500 with rotary connector. Plotter-mounted type.
