108
KEY OPERATOR PROGRAMS
INDEX PRINT
This setting is used to have a black mark (index)
printed at the top of each received fax page.
The position of the mark is shifted with each fax
reception, allowing you to easily distinguish where one
fax reception ends and another begins.
• Enable this function before receiving faxes. The
function remains enabled until you disable it.
• When this function is used, less space is available
on the paper to print the fax image, and thus a
received fax is sometimes divided onto two pages.
• If the received fax is reduced before printing, the
black mark is also reduced.
• When the duplex reception function (page 107) is
enabled to print faxes on both sides of the paper, it is
not recommended that this function be enabled. If
this is done, the black mark will be printed on both
sides of the paper in the same relative position as
when one-sided printing is used.
The setting is initially disabled (no index mark).
1
Follow steps 1 through 6 of "INITIAL
PROCEDURE" (page 96).
2
Select "RCV. FUNCTION" with the [ ] or
[ ] key and then press the [OK] key.
3
Select "INDEX PRINT" with the [ ] or [ ]
key and then press the [OK] key.
•
The setting is enabled (a black mark will be printed)
and a checkmark appears in the checkbox.
• If the procedure is performed when the setting is
enabled, the checkmark will be cleared and the
setting disabled.
EARLIER OUTPUT
When a received fax cannot be printed because the
machine is out of appropriate paper and a fax is
subsequently received that can be printed, this setting
determines whether the subsequent fax is printed before
the fax that cannot be printed. The setting is initially
enabled (the subsequent fax is printed first).
1
Follow steps 1 through 6 of "INITIAL
PROCEDURE" (page 96).
2
Select "RCV. FUNCTION" with the [ ] or
[ ] key and then press the [OK] key.
3
Select "EARLIER OUTPUT" with the [ ] or
[ ] key and then press the [OK] key.
•
The setting is enabled (the subsequent fax is printed
first) and a checkmark appears in the checkbox.
• If the procedure is performed when the setting is
enabled, the checkmark will be cleared and the
setting disabled.
ANTI JUNK FAX
When this setting is enabled, reception from fax
numbers programmed using the "ENTER JUNK FAX
#" program will be blocked.
This program is normally disabled.
1
Follow steps 1 through 6 of "INITIAL
PROCEDURE" (page 96).
2
Select "RCV. FUNCTION" with the [ ] or
[ ] key and then press the [OK] key.
3
Select "ANTI JUNK FAX" with the [ ] or
[ ] key and then press the [OK] key.
• The setting is enabled and a checkmark appears in
the checkbox.
•
If this procedure is performed when the setting is enabled,
the checkmark will be cleared and the setting disabled.
ENTER JUNK FAX #
This program is used to program fax numbers from
which you wish to block reception. Up to 50 fax
numbers can be stored (maximum of 20 digits each).
To block reception from the programmed fax numbers,
the "ANTI JUNK FAX" setting must be enabled.
1
Follow steps 1 through 6 of "INITIAL
PROCEDURE" (page 96).
2
Select "RCV. FUNCTION" with the [ ] or
[ ] key and then press the [OK] key.
3
Select "ENTER JUNK FAX #" with the [ ]
or [ ] key and then press the [OK] key.
4
Select "ENTER" with the [ ] or [ ] key
and then press the [OK] key.
5
Enter a 2-digit control number from 01 to
50 with the numeric keys to identify the fax
number that will be entered in the next
step, and then press the [OK] key.
6
Enter the fax number that you wish to
block with the numeric keys, and then
press the [OK] key.
Prints black
mark
To delete a number, follow these steps: Before
deleting a number, use the "LIST PRINT"
program on (page 97) to check the control
number that identifies the fax number (01 to
50) that you wish to delete. The control number
must be entered to delete the fax number. (The
fax number will not appear in the display. If the
wrong control number is accidentally entered, a
fax number other than the fax number that you
wish to delete will be deleted.)
(1) Select "DELETE" in step 4 and then
press the [OK] key.
(2)
Select the 2-digit control number (01 to
50) that identifies the fax number that
you wish to delete with the [ ] or [ ]
key and then press the [OK] key.
(3) Select "DELETE" with the [ ] or [ ]
key and then press the [OK] key.
Note
Pegasus-E_Fax_Sec.book 108 ページ ２００４年９月２４日 金曜日 午後２時５１分
