Preparation

Closing the viewfinder

Push in the viewfinder completely.

Notes:

• Do not use excessive force when moving

the viewfinder.

• Do not pick up the camcorder by the

viewfinder.

• The viewfinder automatically turns off when

the LCD monitor is opened. If the vertical

rotation of the monitor is 180° when in Tape

Camera or Card Camera mode, however, the

viewfinder is on and the subject is displayed

both in the viewfinder and on the monitor

(see page 40).

• You can adjust the settings on the MENU

screen through the viewfinder by using the

Operation button (see page 31 for use of the

Operation button).

• Be sure to close the viewfinder after use.

Adjusting the diopter

Adjust the diopter according to your

eyesight when the picture in the viewfinder

or the characters on the on-screen display

is not clear.

1 Pull out the viewfinder completely.

2 Hold down the Lock button and set

the Power switch to v.

3 While looking through the viewfinder,

turn the diopter adjustment dial until

the indicators in the viewfinder are

clearly visible.

Note:

• For cleaning the viewfinder, see page 99.

Diopter adjustment dial
