4-11

Display

You can use an external monitor with your computer. To display the images on both

displays simultaneously, use the 1024x768 resolution.

• Some monitors, which are not compatible with your computer, may not

display correctly.

• In this section, you often see the expression “Display Properties dialog

box.” To open the dialog box, right-click somewhere on the Windows

desktop and select Properties from the pop-up menu.

Connecting External Monitor

Use the provided display converter cable to connect an external monitor with your

computer.

1. Turn off your computer and the external monitor.

2. Connect the provided display converter cable with the display cable as shown

below. If the display cable has screws, make sure to tighten them.

Display Cable

Display Converter Cable

Screw
