XG-C430X / XG-C330X
XGA Conference / Classroom Series
XGA Multimedia LCD Projectors
Features & Benefits:
•
High Brightness
XG-C430X: 4,000 ANSI Lumens
XG-C330X: 3,300 ANSI Lumens
•
3-LCD Technology for superior color accuracy
and image detail
•
Two 15-pin RGB inputs permit direct connection
of two PCs (or component sources). A
DVI-D input with HDCP compatibility provides
further PC/Video connectivity. RGB loop-through
enables connection to a desktop monitor or a
second projector
•
Rapid release lens mechanism enables the
standard included lens to be easily replaced
with one of four additional optional special
application lenses
•
Separate and independent composite and
S-Video inputs enable the connection of
“two” video sources
•
Four discrete stereo audio inputs are provided
for use with two RGB and two video sources.
Selectable variable or fixed variable audio
line-out is also included
•
XGA (1024 x 768) native resolution with PC
compatibility up through SXGA+ (1400 x 1050).
HDTV/DTV compatibility (including 1080i, 720p,
480p and 480i) along with PC compatibility up
through SXGA+ (1400 x 1080)
•
Ultra quiet operation (as low as 30 dB in low
power “eco & quiet” mode)
•
Convenient “side access” to lamp and filters
ensures easy maintenance – even when
ceiling mounted
•
RJ-45 LAN terminal for remote control,
monitoring and projector management.
Built-in web browser allows for direct IP
addressing from anywhere on the network
•
Theft deterrent features include key code
(password) startup, Notevision “Lockdown”
through-the-optical-block ceiling mount stud,
optional ceiling mount cable lock system and
Kensington
®
lock compatibility.
•
Wireless Remote with mouse control, page
up/down, image freeze, enlarge and break timer.
Auto Digital Keystone Correction is also
incorporated
P
ro
j
ector •
P
ro
j
ector •
P
ro
j
ector •
P
ro
j
ector •
P
ro
j
ector •
The Sharp Conference/Classroom series XG-C430X (4000 ANSI lumens) and XG-C330X (3300 ANSI
lumens) offer a superior combination of high brightness, high image quality, full feature set, compact size
and affordability.
Utilizing three polysilicon LCDs, these models project brilliant, uniform high quality images for use in
most any educational, corporate, government or house of worship setting. Extensive connectivity
includes built-in LAN (RJ-45) terminal, two 15-pin RGB inputs (selectable for computer or component
sources), DVI-D input with HDCP compatibility, and independent composite and S-Video inputs. Four
stereo audio inputs are provided, as well as selectable variable or fixed audio line-out. There additionally
is RS-232C control, RGB loop-through, and a port for “wired” remote control.
Projection “flexibility” is foremost. In addition to the included standard zoom lens, four optional lenses
are available, making these models adaptable for almost any special application. Plus, with Sharp’s rapid
release lens mechanism, lens changes are quick and effortless.
The XG-C430X and XG-C330X are among the quietest in the industry with a low fan noise of only 30 dB
(low power “eco & quiet” mode). And, with an estimated lamp life of up to 3000 hours (low power “eco
& quiet” mode), cost of operation, as well as lamp changes, are kept to a minimum.
To help ensure “peace of mind” both models incorporate several valuable security features including key
code (password) startup, “through the optical block” ceiling mount bolt, and Kensington
®
Lock
compatibility. Additionally, Network surveillance and monitoring is available through the built-in LAN
(RJ-45) terminal, and an optional heavy-duty ceiling mount cable security system provides extra
protection.
With XGA (1024 x 768) native resolution, with intelligent “ImageACE” resizing, these models offer PC
compatibility up through SXGA+ (1400 x 1050), as well as extensive DTV/HDTV compatibility (in both 4:3
and 16:9) including 1080i, 720p, 480p and 480i.
For use in “commercial” applications, both models are backed by a 2-year parts and
labor limited warranty* (90 days on the user-replaceable projection lamp) including
2 years of Sharp industry-leading “ER” 24-hour turnaround Express Repair support.
HIGH BRIGHTNESS / HIGH IMAGE QUALITY
3-LCD PROJECTORS
Professional Display Division
1
2
